NO LIGHT 800V N-CHANNEL POWER MOSFET ITO-220AB OUTLINE JF JH 4N80F/7N80F/8N80F/10N80F
Product Details:
| Place of Origin: | China |
| Certification: | ISO9001:2015, ISO14001:2015, IATF16949 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3,000 Pieces |
|---|---|
| Price: | Negotiable |
| Delivery Time: | Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, PayPal |
| Supply Ability: | 10000000000piece/Year |
|
Detail Information |
|||
| Model NO.: | 7N80F | Luminous Intensity: | NO LIGHT |
|---|---|---|---|
| Color: | NO LIGHT | Structure: | Planar |
| Material: | Silicon | CURRENT: | 4-20A |
| VOLTAGE: | 800V | PLOARITY: | N-CHANNEL |
| LOGO: | JF AND JH | Transport Package: | Tube |
| Specification: | High Power | Trademark: | JF, JH |
| Origin: | China | HS Code: | 85411000 |
| Supply Ability: | 10000000000piece/Year | Package Size: | 5.58cm * 1.48cm * 0.38cm |
| Package Gross Weight: | 0.001kg | ||
Product Description
N-Channel Power MOSFET
Electronics Component
Part Number: 4N80F/7N80F/8N80F/10N80F
Major Parameter:
| Type | Channel | VDSS(V) | ID(A) (MAX) | PD(W) (MAX) | VGS(V) (MAX) | VTH(V) | @10V (Typ) Rds(on)(Ω) | @10V (max) Rds(on)(Ω) | @4.5V(Typ) Rds(on)(Ω) | ESD protection for G-S(Y/N) | Outline code |
| 4N80 | N | 800 | 4.0 | ±30 | 2~4 | 2.6 | TO-220AB:None ITO-220AB:F TO-263:D TO-252:M TO-262:E TO-251:N TO-247:P SOP-8:S | ||||
| 7N80 | N | 800 | 7.0 | ±30 | 2~4 | 1.6 |
Brand: JF / JH
Package: ITO-220AB/ TO-220AB/ TO-263/ TO-252/ TO-262/ TO-251/ TO-247
Manufacturer: Jinan Jingheng Electronics Co., Ltd.
Features:
· Fast switching capability
· Lead free in compliance with EU RoHS directive.
· Improved dv dt capability high ruggedness
Application:
Used in power supply, lighting, auto, home appliance field
